Viaduct in the context of "Bridge"

An arch bridge is a bridge with abutments at each end shaped as a curved arch. Arch bridges work by transferring the weight of the bridge and its loads partially into a horizontal thrust restrained by the abutments at either side, and partially into a vertical load on the arch supports. A viaduct (a long bridge) may be made from a series of arches, although other more economical structures are typically used today.

A trestle bridge is a bridge composed of a number of short spans supported by closely spaced frames usually carrying a railroad line. A trestle (sometimes tressel) is a rigid frame used as a support, historically a tripod used to support a stool or a pair of isosceles triangles joined at their apices by a plank or beam such as the support structure for a trestle table. Each supporting frame is a bent. A trestle differs from a viaduct in that viaducts have towers that support much longer spans and typically have a higher elevation.

Timber and iron trestles (i.e. bridges) were extensively used in the 19th century, the former making up from 1 to 3 percent of the total length of the average railroad. In the 21st century, steel and sometimes concrete trestles are commonly used to bridge particularly deep valleys, while timber trestles remain common in certain areas.

A boardwalk (alternatively board walk, boarded path, or promenade) is an elevated footpath, walkway, or causeway typically built with wooden planks, which functions as a type of low water bridge or small viaduct that enables pedestrians to better cross wet, muddy or marshy lands. Such timber trackways have existed since at least Neolithic times.

In many seaside resort locations, boardwalks along the beach provide access to shops, hotels, and tourist attractions. The Jersey Shore in the United States is especially noted for its abundance of boardwalks.

The Ribblehead Viaduct or Batty Moss Viaduct carries the Settle–Carlisle railway across Batty Moss in the Ribble Valley at Ribblehead, in North Yorkshire, England. The viaduct, built by the Midland Railway, is 28 miles (45 km) north-west of Skipton and 26 miles (42 km) south-east of Kendal. It is a Grade II* listed structure. Ribblehead Viaduct is the longest and the third tallest structure on the Settle–Carlisle line.

The viaduct was designed by John Sydney Crossley, chief engineer of the Midland Railway, who was responsible for the design and construction of all major structures along the line. The viaduct was necessitated by the challenging terrain of the route. Construction began in late 1869. It necessitated a large workforce, up to 2,300 men, most of whom lived in shanty towns set up near its base. Over 100 men lost their lives during its construction. The Settle to Carlisle line was the last main railway in Britain to be constructed primarily with manual labour.

An elevated railway or elevated train (also known as an el train or el for short) is a railway with the tracks above street level on a viaduct or other elevated structure (usually constructed from steel, cast iron, concrete, or bricks). The railway may be a broad-gauge, standard-gauge or narrow-gauge railway, rapid transit, light rail, monorail, or a suspension railway. Elevated railways are normally found in urban areas that would otherwise require impracticably many level crossings. Usually, the tracks of elevated railways that run on steel viaducts can be seen from street level.

A bridge is a structure designed to span an obstacle, such as a river or valley, allowing vehicles, pedestrians, and other loads to pass across. The Romans and ancient Chinese built major arch bridges of stone and timber. During the Renaissance, advances in science and engineering led to wider bridge spans and more elegant designs. Concrete was perfected in the early 1800s, and proved to be superior to stone in many regards. With the Industrial Revolution came mass-produced steel, which enabled the creation of suspension and cable-stayed bridges that could span wide obstacles. Over time, the maximum achievable span of bridges has steadily increased, reaching 2 kilometers (1.2 miles) in 2022.

Most bridges consist of a flat deck, supported by structures such as beams, arches, or cables. These structures rest on a foundation that is carefully designed to prevent the bridge from settling into the subsoil. Bridges can be constructed in a wide variety of forms, depending on their purpose and location. Notable types include viaducts, which cross wide valleys; trestles to carry heavy trains; and pontoon bridges which float on water.
