⭐ Core Definition: Airspeed

In aviation, airspeed is the speed of an aircraft relative to the air it is flying through (which itself is usually moving relative to the ground due to wind). In contrast, the ground speed is the speed of an aircraft with respect to the surface of the Earth (whether over land or presumed-stationary water). It is difficult to measure the exact airspeed of the aircraft (true airspeed), but other measures of airspeed, such as indicated airspeed and Mach number give useful information about the capabilities and limitations of airplane performance. The common measures of airspeed are:

  • Indicated airspeed (IAS), what is read on an airspeed gauge connected to a pitot-static system.
  • Calibrated airspeed (CAS), indicated airspeed adjusted for pitot system position and installation error.
  • True airspeed (TAS) is the actual speed the airplane is moving through the air. When combined with aircraft direction, wind speed and direction, it can be used to calculate ground speed and direction.
  • Equivalent airspeed (EAS) is true airspeed times root density ratio. It is a useful way of calculating aerodynamic loads and airplane performance at low speeds when the flow can be considered incompressible.
  • Mach number is a measure of how fast the airplane is flying relative to the speed of sound.

The measurement and indication of airspeed is ordinarily accomplished on board an aircraft by an airspeed indicator (ASI) connected to a pitot-static system. The pitot-static system comprises one or more pitot probes (or tubes) facing the on-coming air flow to measure pitot pressure (also called stagnation, total or ram pressure) and one or more static ports to measure the static pressure in the air flow. These two pressures are compared by the ASI to give an IAS reading. Airspeed indicators are designed to give true airspeed at sea level pressure and standard temperature. As the aircraft climbs into less dense air, its true airspeed is greater than the airspeed indicated on the ASI.

↓ Menu

>>>PUT SHARE BUTTONS HERE<<<

πŸ‘‰ Airspeed in the context of True airspeed

The true airspeed (TAS; also KTAS, for knots true airspeed) of an aircraft is the speed of the aircraft relative to the air mass through which it is flying. The true airspeed is important information for accurate navigation of an aircraft. Traditionally it is measured using an analogue TAS indicator, but as GPS has become available for civilian use, the importance of such air-measuring instruments has decreased. Since indicated, as opposed to true, airspeed is a better indicator of margin above the stall, true airspeed is not used for controlling the aircraft; for these purposes the indicated airspeed – IAS or KIAS (knots indicated airspeed) – is used. However, since indicated airspeed only shows true speed through the air at standard sea level pressure and temperature, a TAS meter is necessary for navigation purposes at cruising altitude in less dense air. The IAS meter reads very nearly the TAS at lower altitude and at lower speed. On jet airliners the TAS meter is usually hidden at speeds below 200 knots (370Β km/h). Neither provides for accurate speed over the ground, since surface winds or winds aloft are not taken into account.

↓ Explore More Topics
In this Dossier

Airspeed in the context of Aircraft catapult

An aircraft catapult is an acceleration device used to help fixed-wing aircraft reach liftoff speed (VLOF) faster during takeoff, typically when trying to take off from a very short runway, as otherwise the aircraft engines alone cannot get the aircraft to sufficient airspeed quickly enough for the wings to generate the lift needed to sustain flight. Launching via catapults enables aircraft that typically are only capable of conventional takeoffs, especially heavier aircraft with significant payloads, to perform short takeoffs from the roll distances of light aircraft. Catapults are usually used on the deck of a ship β€” such as the flight deck of an aircraft carrier β€” as a form of assisted takeoff for navalised aircraft, but can also be installed on land-based runways, although this is rare.

Historically it was most common for seaplanes (which have pontoons instead of wheeled landing gears and thus cannot utilize runways) to be catapulted from ships onto nearby water for takeoff, allowing them to conduct aerial reconnaissance missions and be crane-hoisted back on board during retrieval, although by the late First World War their roles are largely supplanted by the more versatile biplanes that can take off and land on carrier decks unassisted. During the Second World War before the advent of escort carriers, monoplane fighter aircraft (notably the Hawker Hurricane) would sometimes be catapulted from "catapult-equipped merchant" (CAM) vessels for one-way sorties to repel enemy aircraft harassing shipping lanes, forcing the returning pilot to either divert to a land-based airstrip, jump out by parachute, or ditch in the water near the convoy and wait for rescue. By the time fleet carriers became the norm in WW2, catapult launches have become largely unnecessary and carrier-based fighter-bombers would routinely perform self-powered takeoffs and landings off and onto carrier decks, especially during the naval aviation-dominated Pacific War between the United States and the Empire of Japan. However, escalating arms races during the Cold War accelerated the adoption of the heavier jet aircraft for naval operations, thus motivating the development of new catapult systems, especially after the popularization of angled flight decks further limited the practical distance available as takeoff runways. Nowadays, jet aircraft can launch from aircraft carriers via either catapults or ski-jump deck, and perform optics-assisted landing onto the same ship with help from decelerative arresting gears.

↑ Return to Menu

Airspeed in the context of Landing gear

Landing gear is the undercarriage of an aircraft or spacecraft that is used for engaging the surface β€” typically land, but may also be the surface of a water body β€” when parking, taxiing, takeoff or landing. It was also formerly called alighting gear by some manufacturers, such as the Glenn L. Martin Company. For aircraft, Stinton makes the terminology distinction undercarriage (British) = landing gear (US).

For aircraft, landing gear is the foundational part of airframe that supports the craft's weight when it is not in flight, keeping the fuselage at a clearance off the ground so it can avoid sustaining frictional/collisional damages. Wheeled landing gear is the most ubiquitous, used in almost all aircraft that perform conventional and short takeoff and landing, while skids or floats are used in aircraft that can take off and land vertically or operate from snow/ice/water. Landing gears from early aircraft are usually fixed, and remain protruded under the aircraft during flight, with no or only partial fairing coverage to reduce drag; while most modern aircraft have retractable undercarriages that fold into the fuselage during flight, which maximizes aerodynamic streamlining and allows for faster airspeeds and smoother flight control.

↑ Return to Menu

Airspeed in the context of Ground speed

Ground speed is the horizontal component of the velocity of an aircraft relative to the Earth’s surface, also referred to as "speed over the ground". It is vital for accurate navigation that the pilot has an estimate of the ground speed that will be achieved during each leg of a flight.

Theoretically, an aircraft diving vertically and unaffected by wind would have a ground speed of zero. Information displayed to passengers through the entertainment system of airline aircraft usually gives the aircraft ground speed rather than airspeed.

↑ Return to Menu

Airspeed in the context of Ski-jump (aviation)

In aviation, a ski-jump is an upwardly curved ramp that allows a fixed-wing aircraft to take off from a runway that is shorter than the aircraft's conventional takeoff requires. By providing an upward vector from the ski-jump's normal force, the aircraft is launched at an elevated angle and lift-off can be achieved at a lower airspeed than that required for flat takeoff, as it allows the aircraft more airborne time after leaving the runway to continue accelerating until enough airspeed has been reached to sustain flight. Ski-jumps are commonly used to launch shipborne aircraft from flight decks of aircraft carriers that lack catapults.

It is believed that the first use of the ski-jump occurred during the Second World War, when a temporary ramp was added to HMSΒ Furious to help heavily laden Fairey Barracudas attack the German battleship Tirpitz. During the Cold War, the concept was studied as a means of reducing the length of flight decks required for aircraft carriers and to facilitate ever-heavier aircraft at sea. The Royal Navy took a particular interest in the ski-jump during the 1970s, conducting tests with the new Hawker Siddeley Harrier VSTOL fighter, then added a ramp to its next generation of aircraft carrier, the Invincible class.

↑ Return to Menu

Airspeed in the context of Cruise speed

Cruise is the phase of aircraft flight from when the aircraft levels off after a climb until it begins to descend for landing. Cruising usually comprises the majority of a flight, and may include small changes in heading (direction of flight), airspeed, and altitude.

↑ Return to Menu

Airspeed in the context of V speeds

In aviation, V-speeds are standard terms used to define airspeeds important or useful to the operation of all aircraft. These speeds are derived from data obtained by aircraft designers and manufacturers during flight testing for aircraft type-certification. Using them is considered a best practice to maximize aviation safety, aircraft performance, or both.

The actual speeds represented by these designators are specific to a particular model of aircraft. They are expressed by the aircraft's indicated airspeed (and not by, for example, the ground speed), so that pilots may use them directly, without having to apply correction factors, as aircraft instruments also show indicated airspeed.

↑ Return to Menu

Airspeed in the context of Spin (flight)

In flight dynamics, a spin is a special category of stall resulting in autorotation (uncommanded roll) about the aircraft's longitudinal axis and a shallow, rotating, downward path approximately centred on a vertical axis. Spins can be entered intentionally or unintentionally, from any flight attitude if the aircraft has sufficient yaw while at the stall point.In a normal spin, the wing on the inside of the turn stalls while the outside wing remains flying. It is possible for both wings to stall, but the angle of attack of each wing, and consequently its lift and drag, are different.

Either situation causes the aircraft to autorotate toward the stalled wing due to its higher drag and loss of lift. Spins are characterized by high angle of attack, an airspeed below the stall on at least one wing and a shallow descent. Recovery and avoiding a crash may require a specific and counter-intuitive set of actions.
