A pen is a common writing instrument that applies ink to a surface, typically paper, for writing or drawing. Early pens such as reed pens, quill pens, dip pens and ruling pens held a small amount of ink on a nib or in a small void or cavity that had to be periodically recharged by dipping the tip of the pen into an inkwell. Today, such pens find only a small number of specialized uses, such as in illustration and calligraphy. Reed pens, quill pens and dip pens, which were used for writing, have been replaced by ballpoint pens, rollerball pens, fountain pens and felt or ceramic tip pens.

Ruling pens, which were used for technical drawing and cartography, have been replaced by technical pens such as the Rapidograph. All of these modern pens contain internal ink reservoirs, such that they do not need to be dipped in ink while writing.

In geometry and science, a cross section is the non-empty intersection of a solid body in three-dimensional space with a plane, or the analog in higher-dimensional spaces. Cutting an object into slices creates many parallel cross-sections. The boundary of a cross-section in three-dimensional space that is parallel to two of the axes, that is, parallel to the plane determined by these axes, is sometimes referred to as a contour line; for example, if a plane cuts through mountains of a raised-relief map parallel to the ground, the result is a contour line in two-dimensional space showing points on the surface of the mountains of equal elevation.

In technical drawing a cross-section, being a projection of an object onto a plane that intersects it, is a common tool used to depict the internal arrangement of a 3-dimensional object in two dimensions. It is traditionally crosshatched with the style of crosshatching often indicating the types of materials being used.

In technical drawing and computer graphics, a multiview projection is a technique of illustration by which a standardized series of orthographic two-dimensional pictures are constructed to represent the form of a three-dimensional object. Up to six pictures of an object are produced (called primary views), with each projection plane parallel to one of the coordinate axes of the object. The views are positioned relative to each other according to either of two schemes: first-angle or third-angle projection. In each, the appearances of views may be thought of as being projected onto planes that form a six-sided box around the object. Although six different sides can be drawn, usually three views of a drawing give enough information to make a three-dimensional object.

These three views are known as front view (also elevation view), top view or plan view and end view (also profile view or section view).

An engineering drawing is a type of technical drawing that is used to convey information about an object. A common use is to specify the geometry necessary for the construction of a component and is called a detail drawing. Usually, a number of drawings are necessary to completely specify even a simple component. These drawings are linked together by a "master drawing." This "master drawing" is more commonly known as an assembly drawing. The assembly drawing gives the drawing numbers of the subsequent detailed components, quantities required, construction materials and possibly 3D images that can be used to locate individual items. Although mostly consisting of pictographic representations, abbreviations and symbols are used for brevity and additional textual explanations may also be provided to convey the necessary information.

The process of producing engineering drawings is often referred to as technical drawing or drafting (draughting). Drawings typically contain multiple views of a component, although additional scratch views may be added of details for further explanation. Only the information that is a requirement is typically specified. Key information such as dimensions is usually only specified in one place on a drawing, avoiding redundancy and the possibility of inconsistency. Suitable tolerances are given for critical dimensions to allow the component to be manufactured and function. More detailed production drawings may be produced based on the information given in an engineering drawing. Drawings have an information box or title block containing who drew the drawing, who approved it, units of dimensions, meaning of views, the title of the drawing and the drawing number.

Computer-aided design (CAD) is the use of computers (or workstations) to aid in the creation, modification, analysis, or optimization of a design. This software is used to increase the productivity of the designer, improve the quality of design, improve communications through documentation, and to create a database for manufacturing. Designs made through CAD software help protect products and inventions when used in patent applications. CAD output is often in the form of electronic files for print, machining, or other manufacturing operations. The terms computer-aided drafting (CAD) and computer-aided design and drafting (CADD) are also used.

Its use in designing electronic systems is known as electronic design automation (EDA). In mechanical design it is known as mechanical design automation (MDA), which includes the process of creating a technical drawing with the use of computer software.

Paper size refers to standardized dimensions for sheets of paper used globally in stationery, printing, and technical drawing. Most countries adhere to the ISO 216 standard, which includes the widely recognized A series (including A4 paper), defined by a consistent aspect ratio of √2. The system, first proposed in the 18th century and formalized in 1975, allows scaling between sizes without distortion. Regional variations exist, such as the North American paper sizes (e.g., Letter, Legal, and Ledger) which are governed by the ANSI and are used in North America and parts of Central and South America.

The standardization of paper sizes emerged from practical needs for efficiency. The ISO 216 system originated in late-18th-century Germany as DIN 476, later adopted internationally for its mathematical precision. The origins of North American sizes are lost in tradition and not well documented, although the Letter size (8.5 in × 11 in (216 mm × 279 mm)) became dominant in the US and Canada due to historical trade practices and governmental adoption in the 20th century. Other historical systems, such as the British Foolscap and Imperial sizes, have largely been phased out in favour of ISO or ANSI standards.

Staedtler SE (German pronunciation: [ˈʃtɛtlɐ]) is a German multinational stationery manufacturing company based in Nuremberg. The firm was founded by J.S. Staedtler (1800–1872) in 1835 and produces a large variety of stationery products, such as writing implements (including technical drawing instruments), art materials, and office supplies.

Staedtler claims to be the largest European manufacturer of wood-cased pencils, overhead projector pens, mechanical pencils, leads, erasers, and modelling clays. Staedtler has over 26 global subsidiaries and nine manufacturing facilities. Almost two thirds of the production is in four facilities in Nuremberg, Germany. Some of its products are made in Japan. Its "Noris" line of pencils is extremely common in British schools.

A writing implement or writing instrument is an object used to produce writing. Writing consists of different figures, lines, and or forms. Most of these items can be also used for other functions such as painting, drawing and technical drawing, but writing instruments generally have the ordinary requirement to create a smooth, controllable line.

Another writing implement employed by a smaller population is the stylus used in conjunction with the slate for punching out the dots in Braille.

A ruling pen is a drawing instrument for drawing with ink or with other drawing fluids. Originally used for technical drawings in engineering and cartography together with straight rulers and French curves, it is today used for specific uses, such as picture framing or calligraphy. Drafting compasses are also sometimes provided with ruling nibs.
