⭐ Core Definition: Resonant

Resonance is a phenomenon that occurs when an object or system is subjected to an external force or vibration whose frequency matches a resonant frequency (or resonance frequency) of the system, defined as a frequency that generates a maximum amplitude response in the system. When this happens, the object or system absorbs energy from the external force and starts vibrating with a larger amplitude. Resonance can occur in various systems, such as mechanical, electrical, or acoustic systems, and it is often desirable in certain applications, such as musical instruments or radio receivers. However, resonance can also be detrimental, leading to excessive vibrations or even structural failure in some cases.

All systems, including molecular systems and particles, tend to vibrate at a natural frequency depending upon their structure; when there is very little damping this frequency is approximately equal to, but slightly above, the resonant frequency. When an oscillating force, an external vibration, is applied at a resonant frequency of a dynamic system, object, or particle, the outside vibration will cause the system to oscillate at a higher amplitude (with more force) than when the same force is applied at other, non-resonant frequencies.

↓ Menu
HINT:

👉 Resonant in the context of Monopole antenna

A monopole antenna is a class of radio antenna consisting of a straight rod-shaped conductor, often mounted perpendicularly over some type of conductive surface, called a ground plane. The current from the transmitter is applied, or for receiving antennas the output signal voltage to the receiver is taken, between the monopole and the ground plane. One side of the feedline to the transmitter or receiver is connected to the lower end of the monopole element, and the other side is connected to the ground plane, which may be the Earth. This contrasts with a dipole antenna which consists of two identical rod conductors, with the current from the transmitter applied between the two halves of the antenna. The monopole antenna is related mathematically to the dipole. The vertical monopole is an omnidirectional antenna with a low gain of 2 - 5 dBi, and radiates most of its power in horizontal directions or low elevation angles. Common types of monopole antenna are the whip, rubber ducky, umbrella, inverted-L and T-antenna, inverted-F, folded unipole antenna, mast radiator, and ground plane antennas.

The monopole is usually used as a resonant antenna; the rod functions as an open resonator for radio waves, oscillating with standing waves of voltage and current along its length. Therefore the length of the antenna is determined by the wavelength of the radio waves it is used with. The most common form is the quarter-wave monopole, in which the antenna is approximately one quarter of the wavelength of the radio waves. It is said to be the most widely used antenna in the world. Monopoles shorter than one-quarter wavelength, called electrically short monopoles, are also widely used since they are more compact. Monopoles five-eights (5/8 = 0.625) of a wavelength long are also common, because at this length a monopole radiates a maximum amount of its power in horizontal directions. A capacitively loaded or top-loaded monopole is a monopole antenna with horizontal conductors such as wires or screens insulated from ground attached to the top of the monopole element, to increase radiated power. Large top-loaded monopoles, the T and inverted L antennas and umbrella antenna are used as transmitting antennas at longer wavelengths, in the LF and VLF bands.
