⭐ Core Definition: Parallax

Parallax is a displacement or difference in the apparent position of an object viewed along two different lines of sight and is measured by the angle or half-angle of inclination between those two lines. Due to foreshortening, nearby objects show a larger parallax than farther objects, so parallax can be used to determine distances.

To measure large distances, such as the distance of a planet or a star from Earth, astronomers use the principle of parallax. Here, the term parallax is the semi-angle of inclination between two sight-lines to the star, as observed when Earth is on opposite sides of the Sun in its orbit. These distances form the lowest rung of what is called "the cosmic distance ladder", the first in a succession of methods by which astronomers determine the distances to celestial objects, serving as a basis for other distance measurements in astronomy forming the higher rungs of the ladder.

↓ Menu

>>>PUT SHARE BUTTONS HERE<<<

👉 Parallax in the context of Monocular

A monocular is a compact refracting telescope used to magnify images of distant objects, typically using an optical prism to ensure an erect image, instead of using relay lenses like most telescopic sights. The volume and weight of a monocular are typically less than half of a pair of binoculars with similar optical properties, making it more portable and also less expensive. This is because binoculars are essentially a pair of monoculars packed together — one for each eye. As a result, monoculars only produce two-dimensional images, while binoculars can use two parallaxed images (each for one eye) to produce binocular vision, which allows stereopsis and depth perception.

Monoculars are ideally suited to those applications where three-dimensional perception is not needed, or where compactness and low weight are important (e.g. hiking). Monoculars are also sometimes preferred where difficulties occur using both eyes through binoculars due to significant eyesight variation (e.g. strabismus, anisometropia or astigmatism) or unilateral visual impairment (due to amblyopia, cataract or corneal ulceration).

↓ Explore More Topics
In this Dossier

Parallax in the context of Parsec

The parsec (symbol: pc) is a unit of length used to measure the large distances to astronomical objects outside the Solar System, approximately equal to 3.26 light-years or 206,265 astronomical units (AU), i.e. 30.9 trillion kilometres (19.2 trillion miles). The parsec unit is obtained by the use of parallax and trigonometry, and is defined as the distance at which 1 AU subtends an angle of one arcsecond (1/3600 of a degree). The nearest star, Proxima Centauri, is about 1.3 parsecs (4.2 light-years) from the Sun: from that distance, the gap between the Earth and the Sun spans slightly less than one arcsecond. Most stars visible to the naked eye are within a few hundred parsecs of the Sun, with the most distant at a few thousand parsecs, and the Andromeda Galaxy at over 700,000 parsecs.

The word parsec is a shortened form of a distance corresponding to a parallax of one second, coined by the British astronomer Herbert Hall Turner in 1913. The unit was introduced to simplify the calculation of astronomical distances from raw observational data. Partly for this reason, it is the unit preferred in astronomy and astrophysics, though in popular science texts and common usage the light-year remains prominent. Although parsecs are used for the shorter distances within the Milky Way, multiples of parsecs are required for the larger scales in the universe, including kiloparsecs (kpc) for the more distant objects within and around the Milky Way, megaparsecs (Mpc) for mid-distance galaxies, and gigaparsecs (Gpc) for many quasars and the most distant galaxies.

↑ Return to Menu

Parallax in the context of Binoculars

Binoculars or field glasses are two refracting telescopes mounted side-by-side and aligned to point in the same direction, allowing the viewer to use both eyes (binocular vision) when viewing distant objects. Most binoculars are sized to be held using both hands, although sizes vary widely from opera glasses to large pedestal-mounted military models.

Unlike a (monocular) telescope, binoculars give users a three-dimensional image: each eyepiece presents a slightly different image to each of the viewer's eyes and the parallax allows the visual cortex to generate an impression of depth.

↑ Return to Menu

Parallax in the context of Autostereogram

An autostereogram is a two-dimensional (2D) image that can create the optical illusion of a three-dimensional (3D) scene. Autostereograms use only one image to accomplish the effect while normal stereograms require two. The 3D scene in an autostereogram is often unrecognizable until it is viewed properly, unlike typical stereograms. Viewing any kind of stereogram properly may cause the viewer to experience vergence-accommodation conflict.

The optical illusion of an autostereogram is one of depth perception and involves stereopsis: depth perception arising from the different perspective each eye has of a three-dimensional scene, called binocular parallax.

↑ Return to Menu

Parallax in the context of Stellar parallax

Stellar parallax is the apparent shift of position (parallax) of any nearby star (or other object) against the background of distant stars. By extension, it is a method for determining the distance to the star through trigonometry, the stellar parallax method. Created by the different orbital positions of Earth, the extremely small observed shift is largest at time intervals of about six months, when Earth arrives at opposite sides of the Sun in its orbit, giving a baseline (the shortest side of the triangle made by a star to be observed and two positions of Earth) distance of about two astronomical units between observations. The parallax itself is considered to be half of this maximum, about equivalent to the observational shift that would occur due to the different positions of Earth and the Sun, a baseline of one astronomical unit (AU).

Stellar parallax is so difficult to detect that its existence was the subject of much debate in astronomy for hundreds of years. Thomas Henderson, Friedrich Georg Wilhelm von Struve, and Friedrich Bessel made the first successful parallax measurements in 1832–1838, for the stars Alpha Centauri, Vega, and 61 Cygni.

↑ Return to Menu

Parallax in the context of Stereopsis

In the science of visual perception, stereopsis is the sensation that objects in space are not flat but extend into depth, and that objects are at different distances from each other. This sensation is much stronger than the suggestion of depth that is created by two-dimensional perspective.

In humans, two mechanisms produce the sensation of stereopsis: binocular depth vision and (monocular) motion vision. In binocular depth vision, the sensation arises from processing differences in retinal images resulting from the two eyes looking from different, but similar, directions (binocular disparity). In motion vision, the sensation arises from processing motion information when the observer moves (e.g. optical flow, parallax). The sensation of stereopsis is similar in both cases.

↑ Return to Menu

Parallax in the context of Hologram

Holography is a technique that allows a wavefront to be recorded and later reconstructed. It is best known as a method of generating three-dimensional images, and has a wide range of other uses, including data storage, microscopy, and interferometry. In principle, it is possible to make a hologram for any type of wave.

A hologram is a recording of an interference pattern that can reproduce a 3D light field using diffraction. In general usage, a hologram is a recording of any type of wavefront in the form of an interference pattern. It can be created by capturing light from a real scene, or it can be generated by a computer, in which case it is known as a computer-generated hologram, which can show virtual objects or scenes. Optical holography needs a laser light to record the light field. The reproduced light field can generate an image that has the depth and parallax of the original scene. A hologram is usually unintelligible when viewed under diffuse ambient light. When suitably lit, the interference pattern diffracts the light into an accurate reproduction of the original light field, and the objects that were in it exhibit visual depth cues such as parallax and perspective that change realistically with the different angles of viewing. That is, the view of the image from different angles shows the subject viewed from similar angles.

↑ Return to Menu

Parallax in the context of Alpha Doradus

Alpha Doradus, Latinized from α Doradus, is the brightest star in the southern constellation of Dorado. The distance to this system, as measured using the parallax method, is about 169 light-years (52 parsecs).

This is a binary star system with an overall apparent visual magnitude that varies between 3.26 and 3.30, making this one of the brightest naked-eye binary stars. The system consists of a subgiant star of spectral type B revolving around a giant star with spectral type A in an eccentric orbit with a period of about 12 years. The orbital separation varies from 2 astronomical units at periastron to 17.5 astronomical units at apastron. The primary, α Doradus A, is a chemically peculiar star whose atmosphere displays an abnormally high abundance of silicon, making this an Si star.
