A bilayer is a double layer of closely packed atoms or molecules.

The properties of bilayers are often studied in condensed matter physics, particularly in the context of semiconductor devices, where two distinct materials are united to form junctions, such as p–n junctions, Schottky junctions, etc. Layered materials, such as graphene, boron nitride, or transition metal dichalcogenides, have unique electronic properties as bilayer systems and are an active area of current research.

↓ Explore More Topics
In this Dossier

P–n junction in the context of Diode

A diode is a two-terminal electronic component that conducts electric current primarily in one direction (asymmetric conductance). It has low (ideally zero) resistance in one direction and high (ideally infinite) resistance in the other.

A semiconductor diode, the most commonly used type today, is a crystalline piece of semiconductor material with a p–n junction connected to two electrical terminals. It has an exponential current–voltage characteristic. Semiconductor diodes were the first semiconductor electronic devices. The discovery of asymmetric electrical conduction across the contact between a crystalline mineral and a metal was made by German physicist Ferdinand Braun in 1874. Today, most diodes are made of silicon, but other semiconducting materials such as gallium arsenide and germanium are also used.

↑ Return to Menu

P–n junction in the context of Laser diode

A laser diode (LD, also injection laser diode or ILD or semiconductor laser or diode laser) is a semiconductor device similar to a light-emitting diode in which a diode pumped directly with electrical current can create lasing conditions at the diode's junction.

Driven by voltage, the doped p–n-transition allows for recombination of an electron with a hole. Due to the drop of the electron from a higher energy level to a lower one, radiation is generated in the form of an emitted photon. This is spontaneous emission. Stimulated emission can be produced when the process is continued and further generates light with the same phase, coherence, and wavelength.

↑ Return to Menu

P–n junction in the context of Bipolar junction transistor

A bipolar junction transistor (BJT) is a type of transistor that uses both electrons and electron holes as charge carriers. In contrast, a unipolar transistor, such as a field-effect transistor (FET), uses only one kind of charge carrier. A bipolar transistor allows a small current injected at one of its terminals to control a much larger current between the remaining two terminals, making the device capable of amplification or switching.

BJTs use two p–n junctions between two semiconductor types, n-type and p-type, which are regions in a single crystal of material. The junctions can be made in several different ways, such as changing the doping of the semiconductor material as it is grown, by depositing metal pellets to form alloy junctions, or by such methods as diffusion of n-type and p-type doping substances into the crystal. The superior predictability and performance of junction transistors quickly displaced the original point-contact transistor. Diffused transistors, along with other components, are elements of integrated circuits for analog and digital functions. Hundreds of bipolar junction transistors can be made in one circuit at a very low cost.

↑ Return to Menu

P–n junction in the context of Electrical junction

An electrical junction is a point or area where (a) two or more conductors or (b) different semiconducting regions of differing electrical properties make physical contact. Electrical junctions types include thermoelectricity junctions, metal–semiconductor junctions and p–n junctions. Junctions are either rectifying or non-rectifying. Non-rectifying junctions comprise ohmic contacts, which are characterised by a linear current–voltage () relation. Electronic components employing rectifying junctions include p–n diodes, Schottky diodes and bipolar junction transistors.

↑ Return to Menu

P–n junction in the context of Cadmium telluride

Cadmium telluride (CdTe) is a stable crystalline compound formed from cadmium and tellurium. It is mainly used as the semiconducting material in cadmium telluride photovoltaics and an infrared optical window. It is usually sandwiched with cadmium sulfide to form a p–n junction solar PV cell.
