⭐ Core Definition: International System of Quantities

The International System of Quantities (ISQ) is a standard system of quantities used in physics and in modern science in general. It includes seven ISQ base quantitieslength, mass, time, electric current, thermodynamic temperature, amount of substance, and luminous intensity – and the relationships between those quantities in derived quantities. This system underlies the International System of Units (SI) but does not itself determine the units of measurement used for the quantities.The system is formally described in a multi-part standard ISO/IEC 80000, which also defines many other derived quantities used in science and technology, first completed in 2009 and subsequently revised and expanded.

↓ Menu

>>>PUT SHARE BUTTONS HERE<<<
In this Dossier

International System of Quantities in the context of Electric current

An electric current is a flow of charged particles, such as electrons or ions, moving through an electrical conductor or space. It is defined as the net rate of flow of electric charge through a surface. The moving particles are called charge carriers, which may be one of several types of particles, depending on the conductor. In electric circuits the charge carriers are often electrons moving through a wire. In semiconductors they can be electrons or holes. In an electrolyte the charge carriers are ions, while in plasma, an ionized gas, they are ions and electrons.

In the International System of Units (SI), electric current is expressed in units of ampere (sometimes called an "amp", symbol A), which is equivalent to one coulomb per second. The ampere is an SI base unit and electric current is a base quantity in the International System of Quantities (ISQ). Electric current is also known as amperage and is measured using a device called an ammeter.

↑ Return to Menu

International System of Quantities in the context of Width

Length is a measure of distance. In the International System of Quantities, length is a quantity with dimension distance. In most systems of measurement a base unit for length is chosen, from which all other units are derived. In the International System of Units (SI) system, the base unit for length is the metre.

Length is commonly understood to mean the most extended dimension of a fixed object. However, this is not always the case and may depend on the position the object is in.

↑ Return to Menu

International System of Quantities in the context of Turn (unit)

The turn (symbol tr or pla) is a unit of plane angle measurement that is the measure of a complete angle—the angle subtended by a complete circle at its center. One turn is equal to 2π radians, 360 degrees or 400 gradians. As an angular unit, one turn also corresponds to one cycle (symbol cyc or c) or to one revolution (symbol rev or r). Common related units of frequency are cycles per second (cps) and revolutions per minute (rpm). The angular unit of the turn is useful in connection with, among other things, electromagnetic coils (e.g., transformers), rotating objects, and the winding number of curves. Divisions of a turn include the half-turn and quarter-turn, spanning a straight angle and a right angle, respectively; metric prefixes can also be used as in, e.g., centiturns (ctr), milliturns (mtr), etc.

In the ISQ, an arbitrary "number of turns" (also known as "number of revolutions" or "number of cycles") is formalized as a dimensionless quantity called rotation, defined as the ratio of a given angle and a full turn. It is represented by the symbol N. (See below for the formula.)

↑ Return to Menu

International System of Quantities in the context of Quotient

In arithmetic, a quotient (from Latin: quotiens 'how many times', pronounced /ˈkwʃənt/) is a quantity produced by the division of two numbers. The quotient has widespread use throughout mathematics. It has two definitions: either the integer part of a division (in the case of Euclidean division) or a fraction or ratio (in the case of a general division). For example, when dividing 20 (the dividend) by 3 (the divisor), the quotient is 6 (with a remainder of 2) in the first sense and (a repeating decimal) in the second sense.

In metrology (International System of Quantities and the International System of Units), "quotient" refers to the general case with respect to the units of measurement of physical quantities. Ratios is the special case for dimensionless quotients of two quantities of the same kind.Quotients with a non-trivial dimension and compound units, especially when the divisor is a duration (e.g., "per second"), are known as rates.For example, density (mass divided by volume, in units of kg/m) is said to be a "quotient", whereas mass fraction (mass divided by mass, in kg/kg or in percent) is a "ratio". Specific quantities are intensive quantities resulting from the quotient of a physical quantity by mass, volume, or other measures of the system "size".

↑ Return to Menu

International System of Quantities in the context of SI base unit

The SI base units are the standard units of measurement defined by the International System of Units (SI) for the seven base quantities of what is now known as the International System of Quantities: they are notably a basic set from which all other SI units can be derived. The units and their physical quantities are the second for time, the metre (sometimes spelled meter) for length or distance, the kilogram for mass, the ampere for electric current, the kelvin for thermodynamic temperature, the mole for amount of substance, and the candela for luminous intensity. The SI base units are a fundamental part of modern metrology, and thus part of the foundation of modern science and technology.

The SI base units form a set of mutually independent dimensions as required by dimensional analysis commonly employed in science and technology.
