In the microelectronics industry, a semiconductor fabrication plant, also called a fab or a foundry, is a factory where integrated circuits (ICs) are manufactured.

The cleanroom is where all fabrication takes place and contains the machinery for integrated circuit production such as steppers and/or scanners for photolithography, etching, cleaning, and doping. All these devices are extremely precise and thus extremely expensive.

In semiconductor fabrication, the International Technology Roadmap for Semiconductors (ITRS) defines the "10 nanometer process" as the MOSFET technology node following the "14 nm" node.

Since at least 1997, "process nodes" have been named purely on a marketing basis, and have no relation to the dimensions on the integrated circuit; neither gate length, metal pitch or gate pitch on a "10nm" device is ten nanometers. For example, GlobalFoundries' "7 nm" processes are dimensionally similar to Intel's "10 nm" process. TSMC and Samsung's "10 nm" processes are somewhere between Intel's "14 nm" and "10 nm" processes in transistor density. The transistor density (number of transistors per square millimetre) is more important than transistor size, since smaller transistors no longer necessarily mean improved performance, or an increase in the number of transistors.
