Flap (aircraft) in the context of Leading edge slats

⭐ Core Definition: Flap (aircraft)

A flap is a high-lift device used to reduce the stalling speed of an aircraft wing at a given weight. Flaps are usually mounted on the wing trailing edges of a fixed-wing aircraft. Flaps are used to reduce the take-off distance and the landing distance. Flaps also cause an increase in drag so they are retracted when not needed.

The flaps installed on most aircraft are partial-span flaps; spanwise from near the wing root to the inboard end of the ailerons. When partial-span flaps are extended they alter the spanwise lift distribution on the wing by causing the inboard half of the wing to supply an increased proportion of the lift, and the outboard half to supply a reduced proportion of the lift. Reducing the proportion of the lift supplied by the outboard half of the wing is accompanied by a reduction in the angle of attack on the outboard half. This is beneficial because it increases the margin above the stall of the outboard half, maintaining aileron effectiveness and reducing the likelihood of asymmetric stall, and spinning. The ideal lift distribution across a wing is elliptical, and extending partial-span flaps causes a significant departure from the elliptical. This increases lift-induced drag which can be beneficial during approach and landing because it allows the aircraft to descend at a steeper angle.

↓ Menu

HINT:

In this Dossier

⭐ Core Definition: Flap (aircraft)
Flap (aircraft) in the context of Wingtip vortices
Flap (aircraft) in the context of Chord (aircraft)

Flap (aircraft) in the context of Wingtip vortices

Wingtip vortices are circular patterns of rotating air left behind a wing as it generates lift. The name is a misnomer because the cores of the vortices are slightly inboard of the wing tips. Wingtip vortices are sometimes named trailing or lift-induced vortices because they also occur at points other than at the wing tips. Indeed, vorticity is trailed at any point on the wing where the lift varies span-wise (a fact described and quantified by the lifting-line theory); it eventually rolls up into large vortices near the wingtip, at the edge of flap devices, or at other abrupt changes in wing planform.

Wingtip vortices are associated with induced drag, the imparting of downwash, and are a fundamental consequence of three-dimensional lift generation. Careful selection of wing geometry (in particular, wingspan), as well as of cruise conditions, are design and operational methods to minimize induced drag.

View the full Wikipedia page for Wingtip vortices

↑ Return to Menu

Flap (aircraft) in the context of Chord (aircraft)

In aeronautics, the chord is an imaginary straight line segment joining the leading edge and trailing edge of an aerofoil cross section parallel to the direction of the airflow. The chord length is the distance between the trailing edge and the leading edge. The point on the leading edge used to define the main chord may be the surface point of minimum radius. For a turbine aerofoil, the chord may be defined by the line between points where the front and rear of a 2-dimensional blade section would touch a flat surface when laid convex-side up.

The wing, horizontal stabilizer, vertical stabilizer and propeller/rotor blades of an aircraft are all based on aerofoil sections, and the term chord or chord length is also used to describe their width. The chord of a wing, stabilizer and propeller is determined by measuring the distance between leading and trailing edges in the direction of the airflow. (If a wing has a rectangular planform, rather than tapered or swept, then the chord is simply the width of the wing measured in the direction of airflow.) The term chord is also applied to the width of wing flaps, ailerons and rudder on an aircraft.

View the full Wikipedia page for Chord (aircraft)
