Compressive strength in the context of Structural system

Ultimate tensile strength (also called UTS, tensile strength, TS, ultimate strength or ${\displaystyle F_{\text{tu}}}$ in notation) is the maximum stress that a material can withstand while being stretched or pulled before breaking. In brittle materials, the ultimate tensile strength is close to the yield point, whereas in ductile materials, the ultimate tensile strength can be higher.

The ultimate tensile strength is usually found by performing a tensile test and recording the engineering stress versus strain. The highest point of the stress–strain curve is the ultimate tensile strength and has units of stress. The equivalent point for the case of compression, instead of tension, is called the compressive strength.

Atmospheric entry (sometimes listed as V_impact or V_entry) is the movement of an object from outer space into and through the gases of an atmosphere of a planet, dwarf planet, or natural satellite. Atmospheric entry may be uncontrolled entry, as in the entry of astronomical objects, space debris, or bolides. It may be controlled entry (or reentry) of a spacecraft that can be navigated or follow a predetermined course. Methods for controlled atmospheric entry, descent, and landing of spacecraft are collectively termed as EDL.

Objects entering an atmosphere experience atmospheric drag, which puts mechanical stress on the object, and aerodynamic heating—caused mostly by compression of the air in front of the object, but also by drag. These forces can cause loss of mass (ablation) or even complete disintegration of smaller objects, and objects with lower compressive strength can explode.

In mechanics, compression is the application of balanced inward ("pushing") forces to different points on a material or structure, that is, forces with no net sum or torque directed so as to reduce its size in one or more directions. It is contrasted with tension or traction, the application of balanced outward ("pulling") forces, and with shearing forces, directed so as to displace layers of the material parallel to each other. The compressive strength of materials and structures is an important engineering consideration.

In uniaxial compression, the forces are directed along one direction only, so that they act towards decreasing the object's length along that direction. The compressive forces may also be applied in multiple directions; for example inwards along the edges of a plate or all over the side surface of a cylinder, so as to reduce its area (biaxial compression), or inwards over the entire surface of a body, so as to reduce its volume.

Bone mineral (also called inorganic bone phase, bone salt, or bone apatite) is the inorganic component of bone tissue. It gives bones their compressive strength. Bone mineral is formed predominantly from carbonated hydroxyapatite with lower crystallinity.

Bone mineral is formed from globular and plate structures distributed among the collagen fibrils of bone and forming yet a larger structure. The bone salt and collagen fibers together constitute the extracellular matrix of bone tissue. Often the plural form "bone salts" is used; it reflects the notion of various salts that, on the level of molecular metabolism, can go into the formation of the hydroxyapatite.

A void or a pore is three-dimensional region that remains unfilled with polymer and fibers in a composite material. Voids are typically the result of poor manufacturing of the material and are generally deemed undesirable. Voids can affect the mechanical properties and lifespan of the composite. They degrade mainly the matrix-dominated properties such as interlaminar shear strength, longitudinal compressive strength, and transverse tensile strength. Voids can act as crack initiation sites as well as allow moisture to penetrate the composite and contribute to the anisotropy of the composite. For aerospace applications, a void content of approximately 1% is still acceptable, while for less sensitive applications, the allowance limit is 3-5%. Although a small increase in void content may not seem to cause significant issues, a 1-3% increase in void content of carbon fiber reinforced composite can reduce the mechanical properties by up to 20%

Compressive stresses are generated in objects when they are subjected to forces that push inward, causing the material to shorten or compress. These stresses occur when an object is squeezed or pressed from opposite directions. In everyday life, compressive stresses are common in many structures and materials. For instance, the weight of a building creates compressive stresses in its walls and foundations. Similarly, when a person stands, the bones in their legs experience compressive stresses due to the weight of the body pushing down. Compressive stresses can lead to deformation if they are strong enough, potentially causing the object to change shape or, in extreme cases, to break. The ability of a material to withstand compressive stresses without failing is known as its compressive strength.

When an object is subjected to a force in a single direction (referred to as a uniaxial compression), the compressive stress is determined by dividing the applied force by the cross-sectional area of the object. Consequently, compressive stress is expressed in units of force per unit area.

In geology, the term compression refers to a set of stresses directed toward the center of a rock mass. Compressive strength refers to the maximum amount of compressive stress that can be applied to a material before failure occurs. When the maximum compressive stress is in a horizontal orientation, thrust faulting can occur, resulting in the shortening and thickening of that portion of the crust. When the maximum compressive stress is vertical, a section of rock will often fail in normal faults, horizontally extending and vertically thinning a given layer of rock. Compressive stresses can also result in the folding of rocks. Because of the large magnitudes of lithostatic stress in tectonic plates, tectonic-scale deformation is always subjected to net compressive stress.

Compressive stresses can result in a number of different features at varying scales, most notably including Folds, and Thrust faults.

In materials science and solid mechanics, Poisson's ratio (symbol: ν (nu)) is a measure of the Poisson effect, the deformation (expansion or contraction) of a material in directions perpendicular to the specific direction of loading. The value of Poisson's ratio is the negative of the ratio of transverse strain to axial strain. For small values of these changes, ν is the amount of transversal elongation divided by the amount of axial compression.

Most materials have Poisson's ratio values ranging between 0.0 and 0.5. For soft materials, such as rubber, where the bulk modulus is much higher than the shear modulus, Poisson's ratio is near 0.5. For open-cell polymer foams, Poisson's ratio is near zero, since the cells tend to collapse in compression. Many typical solids have Poisson's ratios in the range of 0.2 to 0.3.

Self-leveling concrete has polymer-modified cement that has high flow characteristics and, in contrast to traditional concrete, does not require the addition of excessive amounts of water for placement. Self-leveling concrete is typically used to create a flat and smooth surface with a compressive strength similar to or higher than that of traditional concrete prior to installing interior floor coverings. Self-leveling concrete has increased in popularity as the degree of flatness and smoothness required for floor covering products has increased, with vinyl flooring becoming thinner and floor tiles larger, for example.

Self-consolidating (or self-compacting) concrete (SCC) is a separate type of highly mobile (fluid) concrete formulation, which is based on superplasticizers, and is therefore also somewhat self-leveling.
