⭐ Core Definition: Waveguide (electromagnetism)

In radio-frequency engineering and communications engineering, a waveguide is a hollow metal pipe used to carry radio waves. This type of waveguide is used as a transmission line mostly at microwave frequencies, for such purposes as connecting microwave transmitters and receivers to their antennas, in equipment such as microwave ovens, radar sets, satellite communications, and microwave radio links.

The group velocity of guided electromagnetic waves (EMW) is a fraction of the speed of light. Propagation in a (metal-pipe) waveguide may be imagined as a zig-zag path, with the EMW being repeatedly reflected between opposite walls of the guide. For the particular case of rectangular waveguide, it is possible to base an exact analysis on this view. Propagation in a dielectric waveguide may be viewed in the same way, with the waves confined to the dielectric by total internal reflection at its surface. Some structures, such as non-radiative dielectric waveguides and the Goubau line, use both metal walls and dielectric surfaces to confine the wave.

↓ Menu

In this Dossier

Waveguide (electromagnetism) in the context of Wired communication

Wired communication refers to the transmission of data over a wire-based communication technology (telecommunication cables). Wired communication is also known as wireline communication. Examples include telephone networks, cable television or internet access, and fiber-optic communication. Most wired networks use Ethernet cables to transfer data between connected PCs. Also waveguide (electromagnetism), used for high-power applications, is considered wired line. Local telephone networks often form the basis for wired communications and are used by both residential and business customers in the area. Many networks today rely on the use of fiber optic communication technology as a means of providing clear signaling for both inbound and outbound transmissions and are replacing copper wire transmission. Fiber optic technology is capable of accommodating far more signals than copper wiring while still maintaining the integrity of the signal over longer distances.

Alternatively, communication technologies that don't rely on wires to transmit information (voice or data) are considered wireless, and are generally considered to have higher latency and lower reliability.

↑ Return to Menu

Waveguide (electromagnetism) in the context of Distributed-element circuit

Distributed-element circuits are electrical circuits composed of lengths of transmission lines or other distributed components. These circuits perform the same functions as conventional circuits composed of passive components, such as capacitors, inductors, and transformers. They are used mostly at microwave frequencies, where conventional components are difficult (or impossible) to implement.

Conventional circuits consist of individual components manufactured separately then connected together with a conducting medium. Distributed-element circuits are built by forming the medium itself into specific patterns. A major advantage of distributed-element circuits is that they can be produced cheaply as a printed circuit board for consumer products, such as satellite television. They are also made in coaxial and waveguide formats for applications such as radar, satellite communication, and microwave links.

↑ Return to Menu

Waveguide (electromagnetism) in the context of Cavity resonator

A microwave cavity or radio frequency cavity (RF cavity) is a special type of resonator, consisting of a closed (or largely closed) metal structure that confines electromagnetic fields in the microwave or RF region of the spectrum. The structure is either hollow or filled with dielectric material. The microwaves bounce back and forth between the walls of the cavity. At the cavity's resonant frequencies they reinforce to form standing waves in the cavity. Therefore, the cavity functions similarly to an organ pipe or sound box in a musical instrument, oscillating preferentially at a series of frequencies, its resonant frequencies. Thus it can act as a bandpass filter, allowing microwaves of a particular frequency to pass while blocking microwaves at nearby frequencies.

A microwave cavity acts similarly to a resonant circuit with extremely low loss at its frequency of operation, resulting in quality factors (Q factors) up to the order of 10, for copper cavities, compared to 10 for circuits made with separate inductors and capacitors at the same frequency. For superconducting cavities, quality factors up to the order of 10 are possible. They are used in place of resonant circuits at microwave frequencies, since at these frequencies discrete resonant circuits cannot be built because the values of inductance and capacitance needed are too low. They are used in oscillators and transmitters to create microwave signals, and as filters to separate a signal at a given frequency from other signals, in equipment such as radar equipment, microwave relay stations, satellite communications, and microwave ovens.

↑ Return to Menu

Waveguide (electromagnetism) in the context of Microstrip

Microstrip is a type of electrical transmission line which can be fabricated with any technology where a conductor is separated from a ground plane by a dielectric layer known as substrate. Microstrip lines are used to convey microwave-frequency signals.

Typical realisation technologies are printed circuit board (PCB), alumina coated with a dielectric layer or sometimes silicon or some other similar technologies. Microwave components such as antennas, couplers, filters, power dividers etc. can be formed from microstrip, with the entire device existing as the pattern of metallization on the substrate. Microstrip is thus much less expensive than traditional waveguide technology, as well as being far lighter and more compact. Microstrip was developed by ITT laboratories as a competitor to stripline (first published by Grieg and Engelmann in the December 1952 IRE proceedings).

↑ Return to Menu

Waveguide (electromagnetism) in the context of Waveguide flange

A waveguide flange is a connector for joining sections of waveguide, and is essentially the same as a pipe flange—a waveguide, in the context of this article, being a hollow metal conduit for microwave energy. The connecting face of the flange is either square, circular or (particularly for large or reduced-height rectangular waveguides), rectangular. The connection between a pair of flanges is usually made with four or more bolts, though alternative mechanisms, such as a threaded collar, may be used where there is a need for rapid assembly and disassembly. Dowel pins are sometimes used in addition to bolts, to ensure accurate alignment, particularly for very small waveguides.

Key features of a waveguide join are; whether or not it is air-tight, allowing the waveguide to be pressurized, and whether it is a contact or a choke connection. This leads to three sorts of flange for each size of rectangular waveguide.

↑ Return to Menu

Waveguide (electromagnetism) in the context of Parametric amplifier

A parametric oscillator is a driven harmonic oscillator in which the oscillations are driven by varying some parameters of the system at some frequencies, typically different from the natural frequency of the oscillator. A simple example of a parametric oscillator is a child pumping a playground swing by periodically standing and squatting to increase the size of the swing's oscillations. The child's motions vary the moment of inertia of the swing as a pendulum. The "pump" motions of the child must be at twice the frequency of the swing's oscillations. Examples of parameters that may be varied are the oscillator's resonance frequency and damping .

Parametric oscillators are used in several areas of physics. The classical varactor parametric oscillator consists of a semiconductor varactor diode connected to a resonant circuit or cavity resonator. It is driven by varying the diode's capacitance by applying a varying bias voltage. The circuit that varies the diode's capacitance is called the "pump" or "driver". In microwave electronics, waveguide/YAG-based parametric oscillators operate in the same fashion. Another important example is the optical parametric oscillator, which converts an input laser light wave into two output waves of lower frequency ().
