A scan line (also scanline) is one line, or row, in a raster scanning pattern, such as a line of video on a cathode-ray tube (CRT) display of a television set or computer monitor.
On CRT screens the horizontal scan lines are visually discernible, even when viewed from a distance, as alternating colored lines and black lines, especially when a progressive scan signal with below maximum vertical resolution is displayed. This is sometimes used today as a visual effect in computer graphics.
Mechanical television or mechanical scan television is an obsolete television system that relies on a mechanical scanning device, such as a rotating disk with holes in it or a rotating mirror drum, to scan the scene and generate the video signal, and a similar mechanical device at the receiver to display the picture. This contrasts with vacuum tube electronic television technology, using electron beam scanning methods, for example in cathode-ray tube (CRT) televisions. Subsequently, modern solid-state liquid-crystal displays (LCD) and LED displays are now used to create and display television pictures.
Mechanical scanning methods were used in the earliest experimental television systems in the 1920s and 1930s. One of the first experimental wireless television transmissions was by Scottish inventor John Logie Baird on October 2, 1925, in London. By 1928 many radio stations were broadcasting experimental television programs using mechanical systems. However, the technology never produced images of sufficient quality to become popular with the public. Mechanical-scan systems were largely superseded by electronic-scan technology in the mid-1930s, which was used in the first commercially successful television broadcasts that began in the late 1930s. In the U.S., experimental stations such as W2XAB in New York City began broadcasting mechanical television programs in 1931 but discontinued operations on February 20, 1933, until returning with an all-electronic system in 1939.
Video camera tubes are devices based on the cathode-ray tube that were used in television cameras to capture television images, prior to the introduction of charge-coupled device (CCD) image sensors in the 1980s. Several different types of tubes were in use from the early 1930s, and as late as the 1990s.
In these tubes, an electron beam is scanned across an image of the scene to be broadcast focused on a target. This generated a current that is dependent on the brightness of the image on the target at the scan point. The size of the striking ray is tiny compared to the size of the target, allowing 480–486 horizontal scan lines per image in the NTSC format, 576 lines in PAL, and as many as 1035 lines in Hi-Vision.
High-definition video (HD video) is video of higher resolution and quality than standard-definition. While there is no standardized meaning for high-definition, generally any video image with considerably more than 480 vertical scan lines (North America) or 576 vertical lines (Europe) is considered high-definition. 480 scan lines is generally the minimum even though the majority of systems greatly exceed that. Images of standard resolution captured at high frame rate (60 frames/second North America, 50 FPS Europe), by a high-speed camera may be considered high-definition in some contexts. Some television series shot on high-definition video are made to look as if they have been shot on film, a technique which is often known as filmizing.
720p (720 lines progressive) is a progressive HD signal format with 720 horizontal lines/1280 columns and an aspect ratio (AR) of 16:9, normally known as widescreen HD (1.78:1). All major HD broadcasting standards (such as SMPTE 292M) include a 720p format, which has a resolution of 1280×720.
The number 720 stands for the 720 horizontal scan lines of image display resolution (also known as 720 pixels of vertical resolution). The p stands for progressive scan, i.e. non-interlaced. When broadcast at 60 frames per second, 720p features the highest temporal resolution possible under the ATSC and DVB standards. The term assumes a widescreen aspect ratio of 16:9, thus implying a resolution of 1280×720 px (0.9 megapixels).
